Size（mm） | 2440*1350*1100 |
weight（kg） | 512 |
Type of structure | Three piont mounted |
Supporting power (kW) | 46.7-68.8 |
working performance (h ㎡/h) | ≥0.26 |
Power output shaft speed（r/min） | 540 |
Working depth(mm) | 100-220 |
Harvest width (mm) | 1300 |
Rate of harvest % | ≥96 |
Rate of destroy % | ≤1.5 |
Rate of broken skin % | ≤2 |
Standard | NY/T 1130-2006 |
