9YFQ-1.9 Type Square Grass Bunding Machine

Working width

mm

2200

Matching tractor power

kW

≥37

Power output shaft speed

r/min

540

Binding room

cross-sectional area

mm

356X457

Length of straw bundles

mm

305-1321

Density of straw bundles

kg/m³

120-180

  捡拾器

Picker

Width of work

mm

1900

Elastic tooth spacing

mm

66

Minimum ground clearance

mm

25

The number of elastic tooth rods and the number of pick-up elastic teeth

4/64

transmission form

chain transmission

overload protection

safety clutch

送料螺旋

Feeding screw

screw diameter

mm

Out ID.320

Speed

r/min

243

transmission form

Chain Transmission

overload protection

Safty Clutch

Feeding machine

structural style

Crank rocker arm type, 4 feed forks

Rated working frequency

100 times per minute

transmission

Chain Transmission

overload protectionoverload protection

Safety  bolt

压缩装置

compression units

工作速率

Working Speed

次/分

Time/Min.

100

工作行程长度

length of working stroke

mm

550

打捆机构

binding mechanism

打结器数量

Number of knotters

个

2

捆绳箱容量

 Capacity of Rope box

卷

6

成捆率

Binding rate

捆绳打捆

Bundle by rope

﹪

≥98

草捆密度

Bale density

绳打捆稻、麦秸秆
for Paddy and wheat

Kg/m³

≥100

规则草捆率

Regular binding rate

﹪

≥95

喂入量

Feeding quantity

kg/次

2.5

纯工作小时生产率

Pure working hour productivity

kg/h

2500-7200

整机重量

Weight

Kg

1600

Price CIF Panjang by

USD18950/unit
